Insulated Fork Terminals

Drawings of Insulated Fork Terminals

Drawings of Insulated Spade Terminals

Item NO.	UNC	screw dia.	Dimension					Section size（MM²）	Color
Item NO.	UNC	d2(mm)	B(mm)	L(mm)	F(mm)	H(mm)	D φ(mm)	Section size（MM²）	Color
Cable size：0.5～1.5mm2（A.W.G.22～16) max current：Imax=19A material：purple copper　 thickness：0.75mm
SV1.25-3	#4	3.2	5.7	21.2	6.5	10	4.3	0.5~1.5mm² (22-16):Imax=19A	Red
SVS1.25-3.5	#6	3.7	5.7	21.2	6.5
SVL1.25-3.5	#6	3.7	6.4	21.2	6.5
SVS1.25-4	#8	4.3	6.4	21.2	6.5
SVM1.25-4	#8	4.3	7.2	21.2	6.5
SVL1.25-4	#8	4.3	8.1	21.2	6.5
SVS1.25-5	#10	5.3	8.1	21.2	6.5
SVL1.25-5	#10	5.3	9.5	21.2	6.5
SVS1.25-6	1/4	6.5	9.5	21.2	6.5
SVL1.25-6	1/4	6.5	12	21.2	11
Cable size：1.5～2.5mm2（A.W.G.16～14) max current：Imax=27A material：purple copper　 thickness：0.8mm
SV2-3	#4	3.2	5.7	21.2	6.5	10	4.9	1.5~2.5mm² (16~14):Imax=27A	blue
SVS2-3.5	#6	3.7	5.7	21.2	6.5
SVL2-3.5	#6	3.7	6.4	21.2	6.5
SVS2-4	#8	4.3	6	21.2	6.5
SVM2-4	#8	4.3	7.2	21.2	6.5
SVL2-4	#8	4.3	8.1	21.2	6.5
SVS2-5	#10	5.3	8.1	21.2	6.5
SVL2-5	#10	5.3	9.5	21.2	6.5
SVS2-6	1/4	6.5	9.5	21.2	11
SVL2-6	1/4	6.5	12	21.2	7
Cable size：2.5～4mm2（A.W.G.14～12) max current：Imax=37A material：purple copper　 thickness：1.0mm
SV3.5-4	#8	4.3	8	24.8	7	12.5	6.2	2.5~4mm² (14~12):Imax=37A	black
SV3.5-4	#8	4.3	8	24.8	7
SV3.5-5	#10	5.3	8	24.8	12.1
SV3.5-6	1/4	6.5	12	28	7.5
Cable size：4～6mm2（A.W.G.12～10) max current：Imax=48A material：purple copper　 thickness：1.0mm
SV5.5-3.5	#6	3.7	8.3	25.2	7.5	12.5	6.7	4~6mm² (12~10):Imax=48A	yellow
SVS5.5-4	#8	4.3	8.3	25.2	7.5
SVL5.5-4	#8	4.3	9	23.9	7.5
SV5.5-5	#10	5.3	9	23.9	7.5
SVS5.5-6	1/4	6.5	9	23.9	7.5
SVL5.5-6	1/4	6.5	12	31.2	12
SV5.5-8	5/16	8.4	14	30	11.5
